Brand Name: FRIENDLYELEC
Demo Board Type: ARM
Interface: TF Card Support
Interface: USB OTG
ROM Capacity: None
Memory Capacity: 1GB
Processor Brand: Rockchip
Model Number: NanoPi-R2S
Intergrated Feature: 10/100/1000Mbps
CPU: Rockchip RK3328, Quad-core Cortex-A53
DDR4 RAM: 1GB
Network I: Internal 10/100/1000M Ethernet Port x 1
Network II: USB3.0 converted 10/100/1000M Ethernet Port x 1
USB2.0 Host: Type-A x1
MicroUSB: power input and USB Slave
Debug Serial Port: 3.3V TTL, 3-pin 2.54mm pitch connector
LED: LED x 3
KEY: KEY x 1 programmable
Size: 55.6 x 52mm
Power Supply: DC 5V/2A
OS/Software: U-boot/Ubuntu-Core/OpenWrt
